Universal testing machine with four model

Min. Order: 1 Set/Sets

Trade Term: FOB,CFR,CIF,DDP,DAP,EXW

Payment Terms: Paypal, L/C, D/P, D/A, T/T, Money Gram

Place of Origin: Anhui, China (Mainland)

Means of Transport: Ocean, Land

Production Capacity: 50 sets/month

Packing: Wooden box

Delivery Date: 2 ~ 4 weeks

Power: Electronic

Usage: Universal Testing Machine

Brand Name: Anytester

Load cell grade: 0.3

Measuring range: 0.2%~100%F.S

Load resolution: <±0.5%

Test width: 400mm

Speed range: 0.001-500mm/min

Displacement resolution: 1um

Deformation range: 0.2~100%F.S

Power supply: 220V±15% 50Hz,1kw

Output: Color printer

Weight: 320kg

Application:

AT422 Series Universal Testing Machine (original model HY4210) is suitable for tensile, compression, bending, shearing, peeling, tearing and other mechanics performance tests of plastics, rubber, textile, geosynthetics, non-metallic and composite materials. It completely conforms to GB, ISO, ASTM, JIS, DIN and other test standards.

Standard:

Item	Standard Description
Plastics	IS0 527-1993, ISO 604-2002, ISO 178-2004, ISO 1209-1-2007, ISO 1209-2-2007, ASTM D 638-2008 etc.
Rubbers	ISO 37, ISO 34, ISO 5893, ASTM D 2707 etc.
Textile	ASTM D 434, 2261, 3936, 4533, 4964, 5034, 5035, 5735 ISO 2062, 5082, 9073.4, 10321, 4606,13934-1, 13934-2, 13937-2, 13937-3, 13937-4, 13935-1, 13935-2 etc.

Note: For more standards, please contact us

Features:

★ The high stiffness frame incorporates a crosshead guidance system to prevent side loading of the test sample

★ Imported Servo motor and control system, low noisy and high accuracy

★ Imported high accuracy interchangeable load cells (SUNCELLS, USA) (0.5% of reading),having advantages of automatic recognition of the measuring range , controlling parameters and its attributes

★ Professional software have real time display of on-going testing with data, curve, graphic, and table by personal computer

★ Extensometer, inner diameter measurement system and ring stiffness software is available as options

★ Incorporating world proven 32 bit technology for highly accurate load measurement and rapid date acquisition

★ Control system platform is based on TI's DSP control chip, adopt USB connection port

★ Import reducer and ball screw lead support system and A/D converter to provide accurately positioning

★ Three Closed-loop control system for stress, strain, displacement, high accuracy and more stable

★ An extensive built-in library of test methods covering ASTM, ISO, DIN, EN and other test standards

★ Test automation and batch testing, 600 test results available

★ Varieties of grips are provided on customers' requirements

★ The design meets CE requirements for safety.

Technical Specification:

Model	AT422-10	AT422-20	AT422-50	AT422-100
Max. load	10kN	20kN	50kN	100kN
Load cell grade	0.3
Measuring range	0.2% ~ 100% F.S
Load resolution	＜±0.5%
Test travel range	0 ~ 900mm		0 ~ 700mm	0 ~ 500mm
Test width	400mm
